SRC-370SH-4730 Factory Hot selling 4.5V 17500rmp 3.63A output 11.51W

Product Description

PMDC MOTOR Technical Data
Model		Rated Voltage (V)		No-Load		Rated				Stall
		Operating Range	Nominal	Speed	Current	Speed	Current	Torque	Power	Current	Torque
		Operating Range	Nominal	RPM	mA	RPM	mA	mN.m / gf.cm	W	mA	mN.m / gf.cm
RF-370CA	061700	6.0~24.0	24 VDC	1320	3	1000	8	0.98/10	0.1	260	4.02/41
RC-370CH	20123	3.0~6.0	6 VDC	8000	70	6878	420	2.4/24.5	1.71	2550	17/173
RC-370SH	4730	3.0~5.0	4.5 VDC	17500	550	15199	3630	7.2/73.4	11.51	24000	55/561
RC-370SH	18139	6.0~12.0	12 VDC	10000	130	8439	700	5.8/59.2	5.17	3800	37.5/382.5

Click on the tilt font to know more parameters!

Application

Frequently Asked Questions (FAQ)

Q What is the nominal operating voltage of the RC-370SH-4730 micro motor?

The nominal rated voltage of the RC-370SH-4730 model is 4.5V DC, with a functional operating range of 3.0V to 5.0V.

Q What are the key performance specs under no-load conditions?

Under no-load conditions at 4.5V, the motor reaches a high rotation speed of 17,500 RPM with a low current intake of 550 mA.

Q What is the rated output power of this micro PMDC motor?

This motor delivers a rated output power of 11.51W, achieving 15,199 RPM speed and a rated torque of 7.2 mN.m (73.4 gf.cm).

Q How does the motor perform under stall conditions?

When stalled at 4.5V, the motor draws a current of 24,000 mA and outputs a maximum stall torque of 55 mN.m (561 gf.cm).

Q Are there other voltage models available in the 370 series?

Yes, the 370 series includes variations such as the RF-370CA (operating up to 24.0V) and RC-370CH (operating at 6V nominal) to fit diverse design needs.

Q What are the typical applications of these PMDC motors?

These miniature motors are widely utilized in precision machinery, intelligent equipment, automotive accessories, micro-pumps, household smart appliances, and toys.
