Shunli Custom Professional Manufacturer Hair Dryer and Micro Vacuum Cleaner 390PH 12v Dc Motor Brush Brushless

Product Description

Professional manufacturer hair dryer and micro vacuum cleaner 390PH 12v dc motor

Product Details

Motor Customized Specification, Please contact me.

Reference Drawing

RS - 365

RS - 385

RS - 395

The length of shaft can be customized, Please contact me.

Reference Datasheet

PMDC MOTOR Technical Data
Model		Rated Voltage (V)		No-Load		Rated				Stall
		Operating Range	Nominal	Speed	Current	Speed	Current	Torque	Power	Current	Torque
		Operating Range	Nominal	RPM	A	RPM	A	mN.m / gf.cm	W	A	mN.m / gf.cm
RS-390SH	20156R	6.0~12.0	12VDC	5000	0.08	4243	0.33	6.07/61.9	2.72	2.22	42.2/430
RS-390SH	2975	6.0~12.0	12VDC	12000	0.29	10165	0.33	5.75/58.6	1.31	8.9	80.4/820
RS-395SH	15130	6.0~12.0	12VDC	3650	0.66	2949	0.25	5.83/59.5	1.8	1.06	30.4/310
RS-395SH	15100R	6.0~24.0	24VDC	10300	0.07	8893	0.38	7.09/72.3	6.68	2.66	54.9/560

Recommend Product

Frequently Asked Questions (FAQ)

What are the primary applications for the 390PH DC motor?

The 390PH DC motor is customized and designed specifically as a professional motor solution for hair dryers and micro vacuum cleaners.

What voltage range do these micro PMDC motors operate on?

Depending on the exact model, the operating voltage range spans from 6.0V up to 24.0V DC. For example, the RS-390SH models have a nominal voltage of 12VDC, while the RS-395SH (15100R) has a nominal voltage of 24VDC.

Can the shaft length of the motor be customized?

Yes, the length of the shaft can be customized according to your specific dimensional and mechanical design requirements.

What is the difference between the RS-365, RS-385, and RS-395 drawing models?

These designations correspond to different reference drawings and configurations that accommodate varying performance needs, dimension requirements, and power specifications.

What is the max speed and torque for the RS-390SH model?

For the RS-390SH (2975 model) at 12VDC nominal voltage, the no-load speed is 12,000 RPM, and the stall torque reaches up to 80.4 mN.m (820 gf.cm).
